XB866 Mini Auto Range LCD Voltmeter Tester Tool AC/DC Pocket Digital Multimeter Capacimetro Rlc Meter Test | Инструменты

Features: Streamline design and very portable Overrange protection for all ranges Accuacy is specified for a period of year after calibration and at 18 degree to 28 degree  with relative humidity to 75% It includes 7 function with 25 range Max. Voltage Between Terminals And Earth Ground; 600V DC or 500V AC Display: LCD MAX. Show Value: 1999 counts max Polarity Indication:"-" indicates negative polarity Overrange Indication: Display" OL" or "-OL" Sampling Time: approx.0.4second Until showing of function and electrical capacity   Specification: Auto power supply: 15min Power Supply: 1.5Vx2(Not included) Temperature, Factor<0.1*Accuracy/ degree Operating Temperature: 0 degree to 40 degree (32°F to 104 °F) Storage Temperature: 0 degree to 50 degree (10°F to 122 °F) Circumstance Temperature: 23±5 degree Relative Humidity:<70%   Auto Range: DC Voltage: 200mV, 2V, 20V, 200V, 600V AC Voltage: 2V, 20V, 200V, 500V (Frequency Range: 40~400Hz) DC Current: 200uA, 2000uA, 20mA, 200mA AC Current: (Take it only as reference) 200uA(±5% of rdg), 2000uA (±3% of rdg), 20mA (±5% of rdg), 200mA (±3% of rdg) (Frequency Range: 40~400Hz) Resistance: 200Ω, 2KΩ, 20KΩ, 200KΩ, 2MΩ, 20MΩ Diode Test: test current 1mA, test voltage 1.5V DC Continuity: <80Ω Beeper Size: 115x70x20mm Quantity: 1 Pc Note: Please allow 1-3mm error due to manual measurement. pls make sure you do not mind before you bid Due to the difference between different monitors, the picture may not reflect the actual color of the item. Thank you!   1 x Mini LCD Digital Multimeter with 2 test leads 1 x User Manual
