cnc wood working machine atc cnc router 1530 1325 woodworking machine in sri lanka

1)-Model:

iGolden- 1325 ATC 8 Tools

2)-Structure:

Seamless steel welded heavy body

3)-Table:

T slot with water tank, clamps includes

4)-XYZ working size:

1300*2500*200mm

6)-XYZ transmission:

XY axis is helical rack and gear,Z axis Ball Screw

7)-XYZ guide rail:

Famous Taiwan Hiwin Line 25mm Square guide way

8)-Spindle:

9kw ATC HSD air cooled spindle

9)-Spindle collet:

ER32

10)-Inverter:

Well known china Fuling 11kw

11)-Motor:

Japan YASKAWA motors 850W

12)-Driver:

Japan YASKAWA drivers

13)-Controller system:

Taiwan syntec controller system

14)-Voltage:

220v/ 380v, 50/60HZ

15)-Software:

Artcam

16)-Router bits:

20pcs for free

17)-dust collector:

YES

18)-Lubrication:

YES

19)-Vacuum pump:

7.5kw air cooling

20)-Delivery time:

18-20 working days

21)-Packing size:

2280*3200*1900mm

22)-Packing weight:

2200KG

These machines are all popular among different customers. Why not to take one minutes for clicking to get more details. All the specification of machine can be customized according to your own requirements, and there will be one machine suit for you.
