48V Standardized 12 ports PoE Switch with IEEE802.3af/at

  This is a 48V standard POE switch, designed and developed independently by SSC Tech to meet the needs of network power supply. It adopts the latest high-speed Ethernet switching chip, ultra-high backplane bandwidth design, and has extremely fast data processing capabilities to improve smooth data transmission performance ,With 10 power supply network ports, 2 RJ45/uplink ports. Among them, all RJ45 ports support network cable power supply.

it's suitable for Hikvision,DAHUA and other brands with IEEE802.333af/at PoE Powered Devices(PD)

Support EXTEND mode, Max Network Cable length to 250 meters

WARM TIPS: (If you change to the Extend mode, the Max allowable Network Cable length will increased to 250 meters. So we use 52V power adapter. This will avoids the power loss over the long distances, and will make sure the PoE IP Camera working.)

(Please select the consumption according your device power , In order to ensure device stable running, the total power consumption should not exceed 25 watt of the power supply)

If the parameters of your camera are "12V/PoE" , Select this 52V PoE Switch with confidence please,it's suitable for your cameras.

FUNCTION SPECIFICATION

All Port:  The transmission rate of 1-10 Fast Ethernet port is 10/100Mbps (12+, 36-)  and 2 uplink 10/100Mbps transmission rate Fast Ethernet port.

Security:   Independent port and function of current protection

CableType: 3 types and more than 3 types of twisted pair for 10BaseT(No support for

power supply); 5types and more than5 types of twisted pair for 100Base-TX\100Base-TX.

Software specification

Switch Capacity: 2.0G

Exchange mode: store-and-forward

Rate of data signalling: 1-8 port 10/100Mbps and 2 UPlink port 10/100Mbps(Half-duplex mode)

POE Standard: IEEE802.3af/at, each PoE port MAX 30W;

MAC address space: 8K

Mechanical Dimension : 171mm (L)×144mm(W) ×44mm(H)

Input Power: POE208D(8+2 POE switch) /120W/52V;  POE204D(4+2 POE switch)/ 65W/52V; POE112(10+2 POE switch)/ 150W/52V; POE416(16+4 poe switch) /300W/52V; The Max power of each port is 30W

Ambient temperature: Operating Temperature 0℃ to 40℃  / Storage Temperature -40℃ to 70℃

1. PoE switch x1

2. AC Power Cable x1

AC power plug is EU type, if you need other type (US, AU or UK),Please leave a message.

Quality Assurance: 12 Months Warranty from the data of purchase
