Features:

1.Every product has a unique Manufacturing Part Number label on the inner package that proves it has been qualified,which include Part Number,Model Number and inspection date information;

2.If you have any questions about the item,please provide us the Manufacturing Part Number for checking,your profits will be guaranteed.

3.Made of high-quality 45# steel, durable and long service life.

4.It can be used in industrial machinery, trolleys, doors and windows, with a wide range of applications.

5.It can work on a triangle, the load capacity of each caster is 200kg, the load-bearing capacity is strong, and the use effect is good.

Specification:

Color:Yellow

Material:45# Steel

Brand name: BQLZR

Axis Diameter:10mm/0.39inch

Groove Width:19mm/0.75inch

Groove Depth:10mm/0.39inch

Total length:70mm/2.76inch

Wheel Diameter:49mm/1.93inch

Per Wheel Load Capacity:300kg/661Lbs

Bracket Thickness:2.5mm/0.10inch

Bracket Dimensions:68 x 39mm/2.68 x 1.54inch

Installation Pitch:55 x 24mm/2.17 x 0.95inch

Installation Hole Diameter:6.2mm/0.25inch

Total Dimensions:68 x 47.5 x 61mm/2.68 x 1.87 x 2.40inch(L x W x H)

Weight:379g

Note: when you purchase, four wheels load bearing can only equal to the sum of three wheels load bearing, because there is always uneven pavement, four wheels stress are not likely to be evenly.

Package includes:

1 x Groove Rigid Whee
