Features

1. CCID Compliance

2. USB Firmware Upgradability

3. Smart Card Reader:

a) Read/Write speed of up to 424 kbps

b) Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type)

c) Supports ISO 14443 Type A and B cards, FELICA, and all 4 types of NFC (ISO/IEC 18092) tags

d) Supports 7-byte UID, Plus and DESFIRE

e) Built-in anti-collision feature (only one tag is accessed at any time)

f) One ISO 7816 compliant SAM slot

4. Application Programming Interface :

a) Supports PC/SC

b) Supports CT-API (through wrapper on top of PC/SC)

5. Built-in Peripherals:

a) User-controllable bi-color LED

b) User-controllable buzzer

c) SAM Slot

Application

1. E-Government

2. E-Banking and e-Payment

3. E- Health care

4. Transportation

5. Network Security

6. Access Control

7. Loyalty Program

8. Smart Poster

Specifications

Dimensions

98 mm (L) x 65 mm (W) x 12.8 mm (H)

Weight

73g

Interface

USB Full Speed

Operating Distance

Up to 50 mm (depends on the tag type)

Supply Voltage

Regulated 5V DC

Supply Current

200mA (operating)

Operating Temperature

0-50°C

Operating Frequency

13.56 MHz

Smart Card Interface Support

ISO14443 Type A & B

FELICA

4 types of NFC (ISO/IEC18092) tags

Compliance / Certifications

ISO 14443, ISO 18092, ISO 7816, LASCOM, CE, FCC, VCCI, PC/SC, CCID, ROHS, USB Full Speed

Microsoft WHQL: Windows 2000, XP, Vista, 7, 8

Operating System Support

Win 98, Win ME, Win 2000, Win XP, Win Vista, Win 7, Win 8, Win Server 2003, Win Server 2003 R2, Win Server 2008

Win XP x64, Win Vista x64, Win 7 x64, Win 8 x64, Win Server 2003 x64, Win Server 2003 R2 x64, Win Server 2008 x64, Win Server 2008 R2 x64, Win Server 2012 x64

Linux Mac

Android 3.1 and above

Pictures

​FAQ

1.Would you provide SDK for me?
Yes, we offer free SDK if you order sample. All the contents in a CD ROM with sample together.

2. What is the minimum order?
We accept one piece for standard products. If require OEM, will see detailed requirements and confirm MOQ to you from our sales department.

3. What's the delivery time?
Generally, sample can be shipped in 2-3 working days after payment. For quantity, theleading time will be 1-4 weeks depend on exact quantity.

4. Can we get the free sample?

Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation. When they place the mass order, we can return the sample cost to the customers.

5. Do you accept Paypal?
Yes, we accept paypal. Besides, we accept Western Union, T/T, L/C Secure payment (Escrow Service from Alibaba)  and so on.

6.Which way to deliver the goods?

By Express: DHL UPS TNT FEDEX or ARAMEX EMS E-packing.

By Sea: Inform us the Sea Port to check which ship line.

By Air: Inform us the Airport to check which flight.

Or pick up by the customers.

7. Are you manufacturer?
Yes, we are manufacturers. We have been in PC/POS/Mobile Payment product & Solution for 9 years. We can provide OEM / ODM customized service according to our customers’ various application and demands.

8. What warranty for the products?

According to our warranty policy, we will provide 12 months warranty time from the shipment date for our all products (Excluded the consumable parts). As for the mass order, we will provide certain proportion spare parts or RMA machine for local service.

9. What the after sale service?

a. Our all products will provide 12 months warranty;

b. Enough stock spare parts for guarantee;

c. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;
