Asymmetric Button Controller NFC Function Automatic Sleep Wireless Bluetooth Mini Ergonomic Design USB ABS For Nintendo Switch |

Description:
100% brand new and high quality!
Sturdy Ergonomic Design
Mini design size perfect for kids and adults.
Fast-action
Support NFC Function

Item type: mini wireless controller
Material: ABS
Color: As pictures.
Size:15.6x6.4x12.5cm/6.14x2.52x4.92inch
Weight: 268g

1. Mode and connection instructions
Switch mode:
Press Y+Home for 2 seconds to enter the Bluetooth search mode, LED1-LED4 flashes, and the channel indicator corresponding to the successful connection is always on (Switch host allocation);
Sync status, or pairing with the host: LED1-LED4 flashing horse;
Note: After the controller enters the sync mode, it will automatically sleep if there is no synchronization within 2.5 minutes.
Android mode:
Press A+HOME for 2 seconds to enter the Bluetooth search mode. The LEDs are LED2 and LED3. When pairing, the LED flashes quickly and the connection is successful.
2. Connection mode
Press the HOME button for 1 second to wake up the handle. After being woken up, it will automatically connect to the host that is paired with it. If the connection is unsuccessful for 10 seconds, it will automatically sleep; other buttons have no wake-up function.
3. Charging instructions
When the handle is turned off, LED1-LED4 flashes slowly when charging, and the LED is off;
Battery low voltage alarm: The current pass indicator flashes (flashing); the current channel indicator flashes (slow flash) when charging, and the current indicator is always on when fully charged;
When pairing, reconnecting charging or low power, the pairing and returning LEDs indicate priority.
4. Automatic sleep
The host screen is off and the handle is automatically hibernated; in Bluetooth mode, press the HOME button for 5 seconds to disconnect from the host.
Automatically sleeps without any button presses within 5 minutes (including the sensor does not move).
5. Low voltage alarm
When the lithium battery voltage is lower than 3.55V±0.1V, the current channel light flashes promptly that the voltage is low; when the lithium battery voltage is lower than 3.45V±0.1V, it automatically sleeps.
6. Turbo and AutoTurbo features
1, in any mode
Press the (first time) A/B/X/Y/L1/L2/R1/R2 and Turbo keys to set the Turbo function (automatically burst when the button is pressed);
Pressing TURBO again (the second time) realizes the Auto Turbo function (automatic burst when the button is released);
Again (third time) press the A/B/X/Y/L1/L2/R1/R2 and Turbo keys separately to clear the Turbo function of the single button;
Press and hold “—” and the DOWN button at the same time to clear the Turbo function of all buttons.
2, TURBO speed adjustment (there is three speeds can be adjusted, the default is second gear)
Adjustment method: long press 5S TURBO button and then put the right 3D up to the maximum speed will increase by one file
Long press the 5S TURBO button and then hold the right 3D down to the maximum speed.
The third speed is: continuous bursts of 5 times per second (1st gear); continuous bursts of 12 times per second (2 files); continuous bursts of 20 times per second (3 files);
Note: The Turbo function has no memory and no LED indication; the screen capture buttons in PC and Android mode have no function.
7. USB function
Operation mode: Insert SWITCH host automatically recognizes as SWITCH, insert PC into standard XINPPUT mode;
USB LED indicator: SWITCH: Assigned by the host; XINPUT: LED1, LED4 is on.
PC-USB upgrade: Press the L 3 and then plug in the PC-USB to enter the upgrade state. Open the upgrade software and follow the steps to upgrade the controller software.
8. Technical parameters
Shutdown current is less than 15uA,
Pairing current 30~60mA,
Working current (NFC off) 20~30mA, NFC open 80~90mA;
The charging current is 150~200mA.

Package includes:
1* mini wireless controller

Notes:
1. Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!
2. Please allow 1-3cm measuring deviation due to manual measurement.
