DR-75-15 LED Din Rail Switching Power Supply 15V 5A Output

Model: DR-75-15

Input Power points: 110V~220V AC
Output Voltage: 15 DC

Output Rated Current: 0~5A

Output Rated Power: 75W

Model

DR-75-15

DR-75-24

DR-75-48

output

DC voltage

15V

24V

48V

Voltage tolerance

2%

1%

1%

Rated current

5A

3.2A

1.6A

Current range

0~5A

0~3.2A

0~1.6A

Rated power

75W

76.8W

76.8W

Ripple&noise

100mvp-p

150mvp-p

200mvp-p

DCvoltage ADJ.range

-9%~+10%

10%

10%

Input

Voltage range

90~264VAC,127~373VDC

frequency

47~63HZ

AC current

1.6A/110VAC,0.96A/220VAC

efficiency

79%

81%

84%

Inrush current

Cold start current  20A/115VAC,40A/230VAC

Leakage current

< 1mA/240VAC

Protection

Over load

Rated output power110%~150%  start over load protection

protection type :rated current limit ,auto-recovery after fault condition is removed

over voltage

15.6~17.8V

30.6~33.2V

54.8~56.6V

protection type:cutoff output,recovery after restart power

Environment

Working temp,humidity

-20~+60,20%~90%RH

Storagetemp,humidity

-40~+85,10%~95%RH non-condensing

Withstand vibration

10~500HZ,2G 10min/1cycle,period for 60 minutes,each axes

Safety

Withstand voltage

I/P-O/P:3KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC

Isolated resistance

I/P-O/P,I/P-FG,O/P-FG:100M ohms/500VDC

Fitstandard

Safety standard

Fit UL1012

EMC standard

EN55022,CLASSA

others

Dimension

55.5*125.2*100mm (L*W*H)

Weight/packing

0.6kg/20pcs/13kg/0.046m?3;/1.64CUFT

Note

1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25C of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.

3. Tolerance : includes set up tolerance, line regulation and load regulation.

Note: this link is for 75W,15V din rail power supply. If you need other specifications,  pls leave messages to us before payment or find the other correct links from our online Store.  Thank you.
