Rating

Item

Spec.

Rated
voltage Noninductive Load (A) Inductive Load (A) Inrush
Current Resistance Load Lamp Load Inductive Load Motor Load NC NO NC NO NC NO NC NO NC NO 10A 250VAC
8VDC
30VDC
125VDC
250VDC 10
10
6
0.3
0.3 1.5
3
3
0.1
0.05 6
6
6
0.6
0.3 2
3
3
0.1
0.05 24
max. 16A 250VAC
8VDC
30VDC
125VDC
250VDC 16
16
10
0.6
0.3 2
4
4
0.1
0.05 10
10
10
0.6
0.3 3
6
4
0.1
0.05 40
max. 21A 250VAC
8VDC
30VDC
125VDC
250VDC 21
21
14
0.6
0.3 3
5
5
0.1
0.05 12
12
12
0.6
0.3 4
7
5
0.1
0.05 50
max.



Model Designation



Item Code Description Rated Current 10
16
21 10A
16A
21A Actuator 0
1
2
3
4
5
6  Button type
 Long handle type
Short shank type
 Long pulley type
Short pulley type
 Longer handle type
 Crank type Terminal specifications C
D #250 #250 terminal
#187 #187 terminal



Characteristic

Item

CMV 10 CMV 16 CMV 21 Operation speed 0.1mm~1m/s( Button type) Operating frequency Mechanical 240 operations/min
Electrical20 operations/min Insulation resistance 100mΩ above(at 500VDC) Contact resistance 15mΩmax. (initial value) Withstand
voltage Non-continuous terminals 1,000VAC, 50/60Hz 1minute current-carrying and
non-current-carrying
metal parts, Between
terminal and earthing 1,500VAC,
50/60Hz
1minute 2,000VAC, 50/60Hz
1minute Vibration Misoperation 10 to 55Hz,1.5mm pairs swing Shock Durable max1,000m/S2(about100G) Misoperation max200m/S2
(about100G) max300m/S2(about100G) Life Mechanical more than10000000 Electrical 300000times 100000times Temperature -10~+65 Humidity 85%RH(+5~+35)
