РЕК RK2671BM RK2671AM RK2671CM Тестер сопротивления переменному и постоянному напряжению с датчиком давления, точность 5%+3, мощность 200ВА 500ВА 1000ВА включен.

РЕК RK2671BM RK2671AM RK2671CM Тестер сопротивления переменному и постоянному напряжению с датчиком давления точность 5%+3 мощность 200ВА 500ВА 1000ВА включен.

Unavailable in

Model

RK2671AM

RK2671BM

RK2671CM

Output Voltage (KV)

AC

0~5/10

DC

0~5/10

Output Current (MA)

AC

0~2/20

0~2/20/50

0~2/20/100

DC

0~2/10

0~2/20

0~2/20

Test Accuracy

±(5%+3 Words)

Test Time

(0.0~999)S     0.0=Continuous Test

Transformer Capacity

200VA

500VA

1000VA

Interface Of PLC

Optional

Power Requirments

AC:220V±10%   50Hz/60Hz±3Hz

Working Environment

Temperature:(0-40)℃ Humidity≦75%RH

Exterior Dimension

390×310×200mm

443×390×200mm

Weight

14.5kg

25kg

32kg

Accessory

High Voltage Test Line,Grounding Wire,High-Voltage Stick,Power Line(Standard)

The RK2671AM Withstand Voltage Tester Of Meiruike Is The Measurement Instrument For  Compressive Strength,It Mainly Used For Insulation Leakage Safety Test Of Product.It Can Test The Electrical Safety Performance Index Of Breakdown Voltage,Current Of Which All Kind Of The Measured Object Intuitive,Accurate And Fast,And Can Be Used For Testing The Components And Overall Performance As A High Voltage Source.

This Series Of Tester According To The Following Standards:Standard For Household Electrical Appliances(IEC6035,GB4706.1-2001, GB4706.1-1998),Standard For Lamp(IEC60598-1-1999, GB7000.1-2000),Standard For Information (GB8898-2001,GB12113.GB4943-2001, IEC60065,IEC60950) And So On.
Application Area
Components:diode,Triode,High-Voltage Silicon Stack,All Kinds Of Electronic Transformer, Connector Assembly,High Voltage Electrical Equipment.
Household Electric Appliances:TV,Refrigerator,Air Conditioner,Washing Machine,Dryer, Electric Blanket,Charger Etc.
Insulation Material:heat Shrinkable Tube,Capacitor Film,High Pressure Tube,Insulating Paper,Insulated Shoes,Rubber Insulating Gloves,PCB Circuit Board Etc.
Instruments And Meters:oscilloscope,Signal Generator,DC Power Supply,Switching Power Supply And Other Types Of Machine.
Lighting Appliances:ballast,Road Lights,Stage Lights,Portable Lamps And Other Types Of Lamps.
Electric Heating Appliances:electric Drill,Pistol Drill,Cutting Machine,Grinding Machine,Electric Welding Machine Etc.
Wire And Cable:high Voltage Cable,Optic

al Cable,Electric Cable,Silicone Rubber Cable, Etc.
Performance Characteristics
AC/DC Voltage 10kV Universal Withstand Voltage Tester.
The Output Voltage Regulated Output By The Regulator,Which Has High Reliability And High Durability.
Using High Brightness LED Digital Displaying Test Time,Voltage,Current,It Can Display The Breakdown Current Value And Voltage Value In Real Time.
Alarm Current Value Can Be Preset Arbitrarily.
Test Time Using Three Digital Tube Display
